APC's Back-UPS 950 protect your electronic equipment from damage due to power outages, surges and spikes while providing short term battery power during an outage. The Back-UPS 950 features Automatic Voltage Regulation (AVR), which instantly adjusts high and low voltage fluctuations to safe levels for your electronics, saving battery power for when you need it most during storms and power outages. Additionally, Australian sockets make for easy-to-use connection of protected equipment. Specifically designed to protect your PC equipment and network connection in harsh power environments, the Back-UPS 950 ensures maximum productivity and work efficiency Product applications • PC and peripherals • Networking equipment (router, modem) • Game Consoles • LCD / LED TV • Projectors with impulse power Product Features: LED Indicator and Audible Alarms Quickly understand the unit and power status through visual and audible indicators. Automatic Voltage Regulation (AVR) 1 2 work efficiency.
Features
BX950U-AZFeatures
APC Back-UPS 950VA, 230V, AVR, Australian Sockets
Battery Backup & Surge Protector for Electronics and Computers
Includes : USB cable , User Manual
-
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
-
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
-
Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
-
Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse.
-
Telephone dataline surge protection
Provides protection of connected equipment from power surges traveling on telephone lines.
-
USB connection
Use your PC to access additional power protection and management features for your UPS via a USB Port.
Back-UPSFeatures & Benefits
Manageability
Safety
Protection
-
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.
-
Surge only outlets
Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.
Availability
-
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
-
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
-
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Marketing Features
Output
-
Output power capacity
480Watts / 950VA
-
Max Configurable Power (Watts)
480Watts / 950VA
-
Nominal Output Voltage
230V
-
Output Frequency (sync to mains)
50/60 Hz +/-1 Hz
-
Output Frequency (not synced)
50/60 Hz +/-1 Hz
-
Topology
Line Interactive
-
Waveform type
Stepped approximation to a sinewave
-
Output Connections
(6) Australian (Battery Backup)
-
Transfer Time
8ms typical : 10 ms maximum
Input
Batteries & Runtime
Communications & Management
-
Interface Port(s)
USB
-
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators
-
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
-
Surge energy rating
273Joules
-
Data Line Protection
RJ-11 Modem/Fax protection
Physical
-
Maximum Height
215mm , 21.5cm
-
Maximum Width
130mm , 13.0cm
-
Maximum Depth
336mm , 33.6cm
-
Net Weight
8.0kg
-
Shipping weight
8.99kg
-
Shipping Height
295mm , 29.5cm
-
Shipping Width
245mm , 24.5cm
-
Shipping Depth
440mm , 44.0cm
-
Color
Black
Environmental
-
Operating Environment
0 - 40 °C
-
Operating Relative Humidity
0 - 95% no %
-
Operating Elevation
0-3000meters
-
Storage Temperature
-15 - 40 °C
-
Storage Relative Humidity
0 - 95% no %
-
Storage Elevation
0-9000meters
-
Audible noise at 1 meter from surface of unit
45.0dBA
Conformance
-
Approvals
A-tick, C-tick, CE, IEC 62040-1-1, RCM, Telepermit
-
Standard warranty
2 years repair or replace
Sustainable Offer Status
-
RoHS
Compliant
-
REACH
REACH: Contains No SVHCs
