Open Box Sale -- Kingston 4GB 2133MHz DDR4 NON-ECC SODIMM
SKU: KVR21S15S84
Notify me when back in stock
People who viewed this, also viewed
512M x 64-bit (4GB) DDR4-2133 CL15 SDRAM (Synchronous DRAM), 1Rx8, non-ECC, memory module, based on eight 512M x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-2133 timing of 15-15-15 at 1.2V. This 260-pin SODIMM uses gold contact fingers.
Features
• Power Supply: VDD=1.2V Typical
• VDDQ = 1.2V Typical
• VPP - 2.5V Typical
• VDDSPD=2.2V to 3.6V
• Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
• Low-power auto self refresh (LPASR)
• Data bus inversion (DBI) for data bus
• On-die VREFDQ generation and calibration
• Single-rank
• On-board I2 serial presence-detect (SPD) EEPROM
• 16 internal banks; 4 groups of 4 banks each
• Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
• Selectable BC4 or BL8 on-the-fly (OTF)
• Fly-by topology
• Terminated control command and address bus
• PCB: Height 1.18” (30.00mm)
• RoHS Compliant and Halogen-Free
| CL(IDD) | 15 cycles |
| Row Cycle Time (tRCmin) | 46.5ns(min.) |
| Refresh to Active/Refresh | 260ns(min.) |
| Command Time (tRFCmin) | |
| Row Active Time (tRASmin) | 33ns(min.) |
| Maximum Operating Power | TBD W* |
| UL Rating | 94 V - 0 |
| Operating Temperature | 0o C to +85o C |
| Storage Temperature | 55o C to +100o C |
- DDR4,
- 2133MHz,
- Non-ECC,
- CL15,
- 1.2V,
- Unbuffered,
- SODIMM
| SKU | OB-KVR21S15S84 |
| Model # | KVR21S15S84 |
| Brand | Kingston |
| Shipping Weight | 0.0500kg |
| Shipping Width | 0.030m |
| Shipping Height | 0.010m |
| Shipping Length | 0.130m |
| Shipping Cubic | 0.000039000m3 |
| Unit Of Measure | ea |
| Type | store |
